Alloy 825 Nickel Plug and Plug Gasket Incoloy Corrosion Resistance
We are one of the biggest projects pipeline products supplier in China , Our products contain steel pipe/tube,fittings, flanges. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.
Incoloy 825 Tube Plugs, Incoloy 825 Tapered Tube Plugs Manufacturer, Incoloy Alloy 825 Threaded Tapered Plug, Incoloy 825 Heat Exchanger Tube Plugs, Incoloy Alloy 825 Tube Plug.
Incoloy 825 Tube Plug is non-magnetic in the hardened form but may perhaps turn in to magnetic slightly because of welding or cold working. DIN 2.4858 Incoloy Tube Plug is excellent in corrosive atmospheres as in chemical and paper industries along with cryogenic services. Perfect for an extensive range of commercial and home uses.
Incoloy 825 is highly resistant to corrosion. It has a high nickel content, sufficient to resist chloride ion stress corrosion cracking, and a very stable austenite structure. The levels of molybdenum and copper enable the alloy to resist reducing agents and acids. Chromium gives resistance to oxidising conditions, such as nitric acid solutions, nitrates and oxidising salts. The alloy is titanium stabilised to resist pitting and intergranular attack after fabrication, particularly welding, which includes heating in the critical sensitisation temperature range (650°C – 760°C).
Alloy 825 offers exceptional resistance to corrosion by sulphuric and phosphoric acids and is often the most cost effective alloy in sulphuric acid service.
Incoloy 825 Tube Plugs Equivalent Grade
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 825 | N08825 | 2.4858 | NC22DNB4M | NiCr22Mo9Nb | NCF 825 | NA 21 | ЭП703 | ЭИ602 |
Incoloy 825 Tube Plugs Chemical Composition
| Grade | C | Mn | Si | S | Al | Ti | Fe | Ni | Cr |
| Incoloy 825 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 0.40 max | 0.40 max | 5.0 max | 58.0 min | 20.0 - 23.0 |
Incoloy 825 Tube Plugs Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi - 1,35,000 , MPa -930 | Psi - 75,000 , MPa - 517 | 42.50% |
Application:
- Civil Construction Industries
- Ship Building Industries
- Heavy Engineering Industries
- Fertilizer Plants, power Generation Units ( Nuclear, Hydro or Thermal)
- Petro-Chemical Industries
- Civil Industries
- Oil Expansion Projects
- Off Shore & On Shore Oil Towers
- Home Fittings
- Valves
- Vessels
- Pumps
- Railways
- Steel Plants etc.
Heat Treatment
Incoloy 825 is stabilise annealed at 940°C. The softest structure is obtained at 980°C. Sections heavier than sheet, strip and wire should be quenched to avoid sensitisation. Please consult Austral Wright Metals for specific advice on your application.
